Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They make equipment such as boom lifts, aerial lifts and manlifts. These equipments are designed to facilitate access to places which are difficult to reach, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains platforms, or steps or handholds that are attached to the unit in order to transport personnel from every floor.
TB85
The TB85 by Terex provides a maximum working height of 91 feet. Furthermore, the maximum height of the platform reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model offers a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
