Raw Materials
The telescoping boom rough terrain forklift's cab, body, boom and frame are generally produced by a forklift maker. Steel is the most popular materials utilized to make these because they have amazing strength. Sometimes steel forgings or aluminum are also used. It is common for non-metallic materials like for instance nylon plastic blocks to be used as guides in the boom assembly. The other components are usually purchased as finished products and the lift truck manufacturer installs them.
Pre-assembled purchased products can include some of the following: transmission, seat, axles, engine, tires, wheels and hoses, lights, back-up alarms, gauges and hydraulic cylinders. Most often, certain materials like for instance the hydraulic fluid and fuel and lubricants are bought in bulk. These liquids are added as required once the machine is assembled and has passed the rigorous testing sessions.
Design
The narrow and long design of the telescoping boom rough terrain forklift is most common, with a set of wheels at the front of the unit and another set situated towards the rear of the equipment. The model's boom is mounted at the back of the forklift off of a pivot feature which is raised several feet above the frame's level. Normally, the cab is mounted on the left-hand side of the frame structure. Typically, the cab's bottom half is low and situated between the tires. The fuel tank and the hydraulic fuel tank are mounted opposite the cab on the right-hand side. Along the center-line of the vehicle, the engine and the transmission are mounted inside the frame.
Beyond this basic configuration, different manufacturers have contributed to their own unique design. On the market these days, there are numerous options available. Some units of forklifts make use of a single hydraulic cylinder to be able to elevate the boom, and other units make use of 2 cylinders. Several models utilize a side-to-side hydraulic frame leveling capability. This particular feature allows the frame to tilt up to 10 degrees relative to the axles in order to allow the equipment to compensate for extreme axle articulation. This is used for instance, when the tires on one side of the forklift are situated down in a rut and the tires on the other side of the machine are up, located on a mound of dirt.
Another common design feature comprises fork attachments that are capable of swinging up to 45 degrees both left and right, in order to allow accurate load placement.
